FIXED IND 22UH 880MA 335 MOHM
| Inductance | 22 µH |
| Tolerance | ±20% |
| Current Rating | 880 mA |
| DC Resistance (DCR) | 335mOhm |
| saturationCurrent | 900mA |
| Operating Temperature | -40°C ~ 125°C |
| Dimensions | 0.157" L x 0.157" W (4.00mm x 4.00mm) |
| Case / Size | 1616 (4040 Metric) |
| Supplier | Pulse Electronics |
| Description | FIXED IND 22UH 880MA 335 MOHM |
| Series | AWVF |
| productStatus | Active |
| typeConstruction | - |
| coreMaterial | Ferrite |
| shielding | Shielded |
| qFactor | - |
| selfResonantFreq | - |
| ratings | AEC-Q200 |
| testFrequency | 100 kHz |
| mountingType | Surface Mount |
| supplierDevicePackage | 1616 |
| heightMax | 0.075" (1.90mm) |
| features | - |
