FIXED IND 3.3UH 990MA 165 MOHM
| Inductance | 3.3 µH |
| Tolerance | ±20% |
| Current Rating | 990 mA |
| DC Resistance (DCR) | 165mOhm |
| saturationCurrent | 1A |
| Operating Temperature | -40°C ~ 125°C |
| Dimensions | 0.118" L x 0.118" W (3.00mm x 3.00mm) |
| Case / Size | 1212 (3030 Metric) |
| Supplier | Pulse Electronics |
| Description | FIXED IND 3.3UH 990MA 165 MOHM |
| Series | AWVT |
| productStatus | Active |
| typeConstruction | - |
| coreMaterial | - |
| shielding | Unshielded |
| qFactor | - |
| selfResonantFreq | - |
| ratings | AEC-Q200 |
| testFrequency | 1 MHz |
| mountingType | Surface Mount |
| supplierDevicePackage | 1212 |
| heightMax | 0.040" (1.02mm) |
| features | - |
