Description
FIXED IND 18UH 175MA 2.9 OHM TH
Specifications
Parameter Guide
Understand the key electrical and mechanical specifications for B78108T1183J000.
B78108T1183J000 has an inductance value of 18 µH. This value indicates how much magnetic energy the component can store and is one of the first parameters to compare when selecting an inductor.
B78108T1183J000 is rated for 175 mA. Current rating helps determine whether the part can carry the expected DC or RMS current without excessive heating or saturation risk.
B78108T1183J000 lists a DC resistance of 2.9Ohm Max. Lower DCR usually reduces conduction loss and improves efficiency in power circuits.
B78108T1183J000 uses a package or case of Axial. Package size affects PCB footprint, height clearance, thermal behavior, and compatibility with automated assembly.
Explore Related Datasheet Paths
Continue from B78108T1183J000 to manufacturer, series, and broader datasheet collections.
Product Attributes
| Inductance | 18 µH |
| Tolerance | ±5% |
| Current Rating | 175 mA |
| DC Resistance (DCR) | 2.9Ohm Max |
| Operating Temperature | -55°C ~ 125°C |
| Dimensions | 0.130" Dia x 0.276" L (3.30mm x 7.00mm) |
| Case / Size | Axial |
| Package / Case | Axial |
| Supplier | TDK |
| Description | FIXED IND 18UH 175MA 2.9 OHM TH |
| Series | MCC |
| Product Status | Last Time Buy |
| Type / Construction | Drum Core, Wirewound |
| Core Material | Ferrite |
| Shielding | Unshielded |
| Q @ Frequency | 55 @ 2.52MHz |
| Self Resonant Frequency | 40MHz |
| Inductance Test Frequency | 2.52 MHz |
| Mounting Type | Through Hole |
