Description
FIXED IND 22MH 40MA 120 OHM TH
Specifications
Parameter Guide
Understand the key electrical and mechanical specifications for B82144A2226J000.
B82144A2226J000 has an inductance value of 22 mH. This value indicates how much magnetic energy the component can store and is one of the first parameters to compare when selecting an inductor.
B82144A2226J000 is rated for 40 mA. Current rating helps determine whether the part can carry the expected DC or RMS current without excessive heating or saturation risk.
B82144A2226J000 lists a DC resistance of 120Ohm Max. Lower DCR usually reduces conduction loss and improves efficiency in power circuits.
B82144A2226J000 uses a package or case of Axial. Package size affects PCB footprint, height clearance, thermal behavior, and compatibility with automated assembly.
Explore Related Datasheet Paths
Continue from B82144A2226J000 to manufacturer, series, and broader datasheet collections.
Product Attributes
| Inductance | 22 mH |
| Tolerance | ±5% |
| Current Rating | 40 mA |
| DC Resistance (DCR) | 120Ohm Max |
| Operating Temperature | -55°C ~ 125°C |
| Dimensions | 0.205" Dia x 0.472" L (5.20mm x 12.00mm) |
| Case / Size | Axial |
| Package / Case | Axial |
| Supplier | TDK |
| Description | FIXED IND 22MH 40MA 120 OHM TH |
| Series | LBC |
| Product Status | Last Time Buy |
| Type / Construction | Drum Core, Wirewound |
| Core Material | Ferrite |
| Shielding | Unshielded |
| Q @ Frequency | 50 @ 79.6kHz |
| Self Resonant Frequency | 260kHz |
| Inductance Test Frequency | 100 kHz |
| Mounting Type | Through Hole |
