Description
FIXED IND 330UH 330MA 1.9 OHM TH
Specifications
Parameter Guide
Understand the key electrical and mechanical specifications for B82144A2334J000.
B82144A2334J000 has an inductance value of 330 µH. This value indicates how much magnetic energy the component can store and is one of the first parameters to compare when selecting an inductor.
B82144A2334J000 is rated for 330 mA. Current rating helps determine whether the part can carry the expected DC or RMS current without excessive heating or saturation risk.
B82144A2334J000 lists a DC resistance of 1.9Ohm Max. Lower DCR usually reduces conduction loss and improves efficiency in power circuits.
B82144A2334J000 uses a package or case of Axial. Package size affects PCB footprint, height clearance, thermal behavior, and compatibility with automated assembly.
Explore Related Datasheet Paths
Continue from B82144A2334J000 to manufacturer, series, and broader datasheet collections.
Product Attributes
| Inductance | 330 µH |
| Tolerance | ±5% |
| Current Rating | 330 mA |
| DC Resistance (DCR) | 1.9Ohm Max |
| Operating Temperature | -55°C ~ 125°C |
| Dimensions | 0.205" Dia x 0.472" L (5.20mm x 12.00mm) |
| Case / Size | Axial |
| Package / Case | Axial |
| Supplier | TDK |
| Description | FIXED IND 330UH 330MA 1.9 OHM TH |
| Series | LBC |
| Product Status | Last Time Buy |
| Type / Construction | Drum Core, Wirewound |
| Core Material | Ferrite |
| Shielding | Unshielded |
| Q @ Frequency | 50 @ 796kHz |
| Self Resonant Frequency | 2MHz |
| Inductance Test Frequency | 100 kHz |
| Mounting Type | Through Hole |
