Description
FIXED IND 18NH 640MA 120 MOHM
Specifications
Parameter Guide
Understand the key electrical and mechanical specifications for B82412A3180K.
B82412A3180K has an inductance value of 18 nH. This value indicates how much magnetic energy the component can store and is one of the first parameters to compare when selecting an inductor.
B82412A3180K is rated for 640 mA. Current rating helps determine whether the part can carry the expected DC or RMS current without excessive heating or saturation risk.
B82412A3180K lists a DC resistance of 120mOhm Max. Lower DCR usually reduces conduction loss and improves efficiency in power circuits.
B82412A3180K uses a package or case of 2-SMD. Package size affects PCB footprint, height clearance, thermal behavior, and compatibility with automated assembly.
Explore Related Datasheet Paths
Continue from B82412A3180K to manufacturer, series, and broader datasheet collections.
Product Attributes
| Inductance | 18 nH |
| Tolerance | ±10% |
| Current Rating | 640 mA |
| DC Resistance (DCR) | 120mOhm Max |
| Saturation Current | - |
| Operating Temperature | -55°C ~ 125°C |
| Dimensions | 0.126" L x 0.098" W (3.20mm x 2.50mm) |
| Case / Size | 2-SMD |
| Package / Case | 2-SMD |
| Supplier | TDK |
| Description | FIXED IND 18NH 640MA 120 MOHM |
| Series | SIMID |
| Product Status | Obsolete |
| Type / Construction | Drum Core, Wirewound |
| Core Material | Ceramic |
| Shielding | Unshielded |
| Q @ Frequency | 30 @ 100MHz |
| Self Resonant Frequency | 2.7GHz |
| Ratings | AEC-Q200 |
| Inductance Test Frequency | 10 MHz |
| Mounting Type | Surface Mount |
| Supplier Device Package | 1210 (3225 Metric) |
| Height - Seated (Max) | 0.075" (1.90mm) |
| Features | - |
