FIXED IND 2.2UH 35A 2.53 MOHM
| Inductance | 2.2 µH |
| Tolerance | ±20% |
| Current Rating | 35 A |
| DC Resistance (DCR) | 2.53mOhm Max |
| saturationCurrent | 62A |
| Operating Temperature | -55°C ~ 125°C |
| Dimensions | 0.693" L x 0.677" W (17.60mm x 17.20mm) |
| Case / Size | Nonstandard |
| Supplier | Pulse Electronics |
| Description | FIXED IND 2.2UH 35A 2.53 MOHM |
| Series | BMMA |
| productStatus | Active |
| typeConstruction | Molded |
| coreMaterial | - |
| shielding | Shielded |
| qFactor | - |
| selfResonantFreq | - |
| ratings | - |
| testFrequency | 100 kHz |
| mountingType | Surface Mount |
| supplierDevicePackage | - |
| heightMax | 0.276" (7.00mm) |
| features | - |
