Description
FIXED IND 330NH 6A 14 MOHM SMD
Specifications
Parameter Guide
Understand the key electrical and mechanical specifications for BMQE00040410R33MAA.
BMQE00040410R33MAA has an inductance value of 330 nH. This value indicates how much magnetic energy the component can store and is one of the first parameters to compare when selecting an inductor.
BMQE00040410R33MAA is rated for 6 A. Current rating helps determine whether the part can carry the expected DC or RMS current without excessive heating or saturation risk.
BMQE00040410R33MAA lists a DC resistance of 14mOhm Max. Lower DCR usually reduces conduction loss and improves efficiency in power circuits.
BMQE00040410R33MAA uses a package or case of Nonstandard. Package size affects PCB footprint, height clearance, thermal behavior, and compatibility with automated assembly.
Explore Related Datasheet Paths
Continue from BMQE00040410R33MAA to manufacturer, series, and broader datasheet collections.
Alternative Solutions
Compare possible alternatives with similar specifications. Verify every electrical and mechanical requirement before use.
Product Attributes
| Inductance | 330 nH |
| Tolerance | ±20% |
| Current Rating | 6 A |
| DC Resistance (DCR) | 14mOhm Max |
| Saturation Current | 9A |
| Operating Temperature | -55°C ~ 125°C |
| Dimensions | 0.181" L x 0.161" W (4.60mm x 4.10mm) |
| Case / Size | Nonstandard |
| Package / Case | Nonstandard |
| Supplier | Pulse Electronics |
| Description | FIXED IND 330NH 6A 14 MOHM SMD |
| Series | BMQx |
| Product Status | Active |
| Type / Construction | Molded |
| Shielding | Shielded |
| Inductance Test Frequency | 100 kHz |
| Mounting Type | Surface Mount |
| Height - Seated (Max) | 0.039" (1.00mm) |
