Description
FIXED IND 15UH 2.8A 55 MOHM SMD
Specifications
Parameter Guide
Understand the key electrical and mechanical specifications for BPAS00080845150M00.
BPAS00080845150M00 has an inductance value of 15 µH. This value indicates how much magnetic energy the component can store and is one of the first parameters to compare when selecting an inductor.
BPAS00080845150M00 is rated for 2.8 A. Current rating helps determine whether the part can carry the expected DC or RMS current without excessive heating or saturation risk.
BPAS00080845150M00 lists a DC resistance of 55mOhm Max. Lower DCR usually reduces conduction loss and improves efficiency in power circuits.
BPAS00080845150M00 uses a package or case of Nonstandard. Package size affects PCB footprint, height clearance, thermal behavior, and compatibility with automated assembly.
Explore Related Datasheet Paths
Continue from BPAS00080845150M00 to manufacturer, series, and broader datasheet collections.
Similar-specification candidates · Engineering review required
Screened against recorded construction, core, mounting, dimensions and current/DCR. Land pattern, test conditions and circuit compatibility still require validation.
Missing evidence or no candidates passed screening. A replacement cannot be determined; request a review of the original datasheets.
Product Attributes
| Inductance | 15 µH |
| Tolerance | ±20% |
| Current Rating | 2.8 A |
| DC Resistance (DCR) | 55mOhm Max |
| Saturation Current | 2.3A |
| Operating Temperature | -40°C ~ 125°C |
| Dimensions | 0.374" L x 0.295" W (9.50mm x 7.50mm) |
| Case / Size | Nonstandard |
| Package / Case | Nonstandard |
| Supplier | Pulse Electronics |
| Description | FIXED IND 15UH 2.8A 55 MOHM SMD |
| Series | BPAS |
| Product Status | Active |
| Shielding | Shielded |
| Inductance Test Frequency | 100 kHz |
| Mounting Type | Surface Mount |
| Height - Seated (Max) | 0.177" (4.50mm) |
