FIXED IND 1UH 4.8A 14.3 MOHM SMD
| Inductance | 1 µH |
| Tolerance | ±30% |
| Current Rating | 4.8 A |
| DC Resistance (DCR) | 14.3mOhm Max |
| saturationCurrent | 6A |
| Operating Temperature | -40°C ~ 105°C |
| Dimensions | 0.248" L x 0.236" W (6.30mm x 6.00mm) |
| Case / Size | Nonstandard |
| Supplier | Pulse Electronics |
| Description | FIXED IND 1UH 4.8A 14.3 MOHM SMD |
| Series | BPCA |
| productStatus | Active |
| typeConstruction | - |
| coreMaterial | Ferrite |
| shielding | Shielded |
| qFactor | - |
| selfResonantFreq | - |
| ratings | - |
| testFrequency | 100 kHz |
| mountingType | Surface Mount |
| supplierDevicePackage | - |
| heightMax | 0.193" (4.90mm) |
| features | - |
