Description
FIXED IND 330UH 490MA 1.104 OHM
Specifications
Parameter Guide
Understand the key electrical and mechanical specifications for BPCA00060645331M00.
BPCA00060645331M00 has an inductance value of 330 µH. This value indicates how much magnetic energy the component can store and is one of the first parameters to compare when selecting an inductor.
BPCA00060645331M00 is rated for 490 mA. Current rating helps determine whether the part can carry the expected DC or RMS current without excessive heating or saturation risk.
BPCA00060645331M00 lists a DC resistance of 1.104Ohm Max. Lower DCR usually reduces conduction loss and improves efficiency in power circuits.
BPCA00060645331M00 uses a package or case of Nonstandard. Package size affects PCB footprint, height clearance, thermal behavior, and compatibility with automated assembly.
Explore Related Datasheet Paths
Continue from BPCA00060645331M00 to manufacturer, series, and broader datasheet collections.
Similar-specification candidates · Engineering review required
Screened against recorded construction, core, mounting, dimensions and current/DCR. Land pattern, test conditions and circuit compatibility still require validation.
Missing evidence or no candidates passed screening. A replacement cannot be determined; request a review of the original datasheets.
Product Attributes
| Inductance | 330 µH |
| Tolerance | ±20% |
| Current Rating | 490 mA |
| DC Resistance (DCR) | 1.104Ohm Max |
| Saturation Current | 280mA |
| Operating Temperature | -40°C ~ 105°C |
| Dimensions | 0.248" L x 0.236" W (6.30mm x 6.00mm) |
| Case / Size | Nonstandard |
| Package / Case | Nonstandard |
| Supplier | Pulse Electronics |
| Description | FIXED IND 330UH 490MA 1.104 OHM |
| Series | BPCA |
| Product Status | Active |
| Core Material | Ferrite |
| Shielding | Shielded |
| Inductance Test Frequency | 100 kHz |
| Mounting Type | Surface Mount |
| Height - Seated (Max) | 0.193" (4.90mm) |
