FIXED IND 1.8UH 10A 19.1 MOHM
| Inductance | 1.8 µH |
| Tolerance | ±30% |
| Current Rating | 10 A |
| DC Resistance (DCR) | 19.1mOhm Max |
| saturationCurrent | 10.2A |
| Operating Temperature | -40°C ~ 125°C |
| Dimensions | 0.406" L x 0.406" W (10.30mm x 10.30mm) |
| Case / Size | Nonstandard |
| Supplier | Pulse Electronics |
| Description | FIXED IND 1.8UH 10A 19.1 MOHM |
| Series | BPCI |
| productStatus | Active |
| typeConstruction | Multilayer |
| coreMaterial | Ferrite |
| shielding | Shielded |
| qFactor | - |
| selfResonantFreq | - |
| ratings | - |
| testFrequency | 100 kHz |
| mountingType | Surface Mount |
| supplierDevicePackage | - |
| heightMax | 0.157" (4.00mm) |
| features | - |
