Description
FIXED IND 33UH 2.3A 101 MOHM SMD
Specifications
Parameter Guide
Understand the key electrical and mechanical specifications for BPRR00101041330MA0.
BPRR00101041330MA0 has an inductance value of 33 µH. This value indicates how much magnetic energy the component can store and is one of the first parameters to compare when selecting an inductor.
BPRR00101041330MA0 is rated for 2.3 A. Current rating helps determine whether the part can carry the expected DC or RMS current without excessive heating or saturation risk.
BPRR00101041330MA0 lists a DC resistance of 101mOhm Max. Lower DCR usually reduces conduction loss and improves efficiency in power circuits.
BPRR00101041330MA0 uses a package or case of Nonstandard. Package size affects PCB footprint, height clearance, thermal behavior, and compatibility with automated assembly.
Explore Related Datasheet Paths
Continue from BPRR00101041330MA0 to manufacturer, series, and broader datasheet collections.
Product Attributes
| Inductance | 33 µH |
| Tolerance | ±20% |
| Current Rating | 2.3 A |
| DC Resistance (DCR) | 101mOhm Max |
| Saturation Current | 3.5A |
| Operating Temperature | -40°C ~ 125°C |
| Dimensions | 0.398" L x 0.394" W (10.10mm x 10.00mm) |
| Case / Size | Nonstandard |
| Package / Case | Nonstandard |
| Supplier | Pulse Electronics |
| Description | FIXED IND 33UH 2.3A 101 MOHM SMD |
| Series | BPRR |
| Product Status | Active |
| Type / Construction | - |
| Core Material | Ferrite |
| Shielding | Shielded |
| Q @ Frequency | - |
| Self Resonant Frequency | - |
| Ratings | - |
| Inductance Test Frequency | 100 kHz |
| Mounting Type | Surface Mount |
| Supplier Device Package | - |
| Height - Seated (Max) | 0.161" (4.10mm) |
| Features | - |
