Description
FIXED IND 8.2UH 4.2A 30 MOHM SMD
Specifications
Parameter Guide
Understand the key electrical and mechanical specifications for BPRR001010418R2T00.
BPRR001010418R2T00 has an inductance value of 8.2 µH. This value indicates how much magnetic energy the component can store and is one of the first parameters to compare when selecting an inductor.
BPRR001010418R2T00 is rated for 4.2 A. Current rating helps determine whether the part can carry the expected DC or RMS current without excessive heating or saturation risk.
BPRR001010418R2T00 lists a DC resistance of 30mOhm Max. Lower DCR usually reduces conduction loss and improves efficiency in power circuits.
BPRR001010418R2T00 uses a package or case of Nonstandard. Package size affects PCB footprint, height clearance, thermal behavior, and compatibility with automated assembly.
Explore Related Datasheet Paths
Continue from BPRR001010418R2T00 to manufacturer, series, and broader datasheet collections.
Product Attributes
| Inductance | 8.2 µH |
| Tolerance | ±30% |
| Current Rating | 4.2 A |
| DC Resistance (DCR) | 30mOhm Max |
| Saturation Current | 4.5A |
| Operating Temperature | -40°C ~ 125°C |
| Dimensions | 0.398" L x 0.394" W (10.10mm x 10.00mm) |
| Case / Size | Nonstandard |
| Package / Case | Nonstandard |
| Supplier | Pulse Electronics |
| Description | FIXED IND 8.2UH 4.2A 30 MOHM SMD |
| Series | BPRR |
| Product Status | Active |
| Type / Construction | - |
| Core Material | Ferrite |
| Shielding | Shielded |
| Q @ Frequency | - |
| Self Resonant Frequency | - |
| Ratings | - |
| Inductance Test Frequency | 100 kHz |
| Mounting Type | Surface Mount |
| Supplier Device Package | - |
| Height - Seated (Max) | 0.161" (4.10mm) |
| Features | - |
