BPRR00101051331K00
Pulse Electronics
Description
FIXED IND 330UH 730MA 812 MOHM
Specifications
Parameter Guide
Understand the key electrical and mechanical specifications for BPRR00101051331K00.
BPRR00101051331K00 has an inductance value of 330 µH. This value indicates how much magnetic energy the component can store and is one of the first parameters to compare when selecting an inductor.
BPRR00101051331K00 is rated for 730 mA. Current rating helps determine whether the part can carry the expected DC or RMS current without excessive heating or saturation risk.
BPRR00101051331K00 lists a DC resistance of 812mOhm Max. Lower DCR usually reduces conduction loss and improves efficiency in power circuits.
BPRR00101051331K00 uses a package or case of Nonstandard. Package size affects PCB footprint, height clearance, thermal behavior, and compatibility with automated assembly.
Explore Related Datasheet Paths
Continue from BPRR00101051331K00 to manufacturer, series, and broader datasheet collections.
Alternative Solutions
Compare possible alternatives with similar specifications. Verify every electrical and mechanical requirement before use.
Product Attributes
| Inductance | 330 µH |
| Tolerance | ±10% |
| Current Rating | 730 mA |
| DC Resistance (DCR) | 812mOhm Max |
| Saturation Current | 750mA |
| Operating Temperature | -40°C ~ 125°C |
| Dimensions | 0.398" L x 0.394" W (10.10mm x 10.00mm) |
| Case / Size | Nonstandard |
| Package / Case | Nonstandard |
| Supplier | Pulse Electronics |
| Description | FIXED IND 330UH 730MA 812 MOHM |
| Series | BPRR |
| Product Status | Active |
| Core Material | Ferrite |
| Shielding | Shielded |
| Inductance Test Frequency | 100 kHz |
| Mounting Type | Surface Mount |
| Height - Seated (Max) | 0.201" (5.10mm) |
