Description
FIXED IND 2UH 40A 1.4 MOHM SMD
Specifications
Parameter Guide
Understand the key electrical and mechanical specifications for BPSP001909112R0M00.
BPSP001909112R0M00 has an inductance value of 2 µH. This value indicates how much magnetic energy the component can store and is one of the first parameters to compare when selecting an inductor.
BPSP001909112R0M00 is rated for 40 A. Current rating helps determine whether the part can carry the expected DC or RMS current without excessive heating or saturation risk.
BPSP001909112R0M00 lists a DC resistance of 1.4mOhm Max. Lower DCR usually reduces conduction loss and improves efficiency in power circuits.
BPSP001909112R0M00 uses a package or case of Nonstandard, 3 Lead. Package size affects PCB footprint, height clearance, thermal behavior, and compatibility with automated assembly.
Explore Related Datasheet Paths
Continue from BPSP001909112R0M00 to manufacturer, series, and broader datasheet collections.
Alternative Solutions
Compare possible alternatives with similar specifications. Verify every electrical and mechanical requirement before use.
Product Attributes
| Inductance | 2 µH |
| Tolerance | ±20% |
| Current Rating | 40 A |
| DC Resistance (DCR) | 1.4mOhm Max |
| Saturation Current | 34.4A |
| Operating Temperature | -40°C ~ 125°C |
| Dimensions | 0.748" L x 0.736" W (19.00mm x 18.70mm) |
| Case / Size | Nonstandard, 3 Lead |
| Package / Case | Nonstandard, 3 Lead |
| Supplier | Pulse Electronics |
| Description | FIXED IND 2UH 40A 1.4 MOHM SMD |
| Series | BPSP |
| Product Status | Active |
| Type / Construction | Wirewound |
| Shielding | Shielded |
| Self Resonant Frequency | 39MHz |
| Inductance Test Frequency | 100 kHz |
| Mounting Type | Surface Mount |
| Height - Seated (Max) | 0.420" (10.67mm) |
