FIXED IND 1UH 6.22A 14.28 MOHM
| Inductance | 1 µH |
| Tolerance | ±30% |
| Current Rating | 6.22 A |
| DC Resistance (DCR) | 14.28mOhm Max |
| saturationCurrent | 8.3A |
| Operating Temperature | -40°C ~ 105°C |
| Dimensions | 0.343" L x 0.291" W (8.70mm x 7.40mm) |
| Case / Size | Nonstandard |
| Supplier | Pulse Electronics |
| Description | FIXED IND 1UH 6.22A 14.28 MOHM |
| Series | BPSS |
| productStatus | Active |
| typeConstruction | - |
| coreMaterial | - |
| shielding | Shielded |
| qFactor | - |
| selfResonantFreq | - |
| ratings | - |
| testFrequency | 100 kHz |
| mountingType | Surface Mount |
| supplierDevicePackage | - |
| heightMax | 0.098" (2.50mm) |
| features | - |
