FIXED IND 6.8UH 2.7A 66.3 MOHM
| Inductance | 6.8 µH |
| Tolerance | ±20% |
| Current Rating | 2.7 A |
| DC Resistance (DCR) | 66.3mOhm Max |
| saturationCurrent | 3.5A |
| Operating Temperature | -40°C ~ 105°C |
| Dimensions | 0.343" L x 0.291" W (8.70mm x 7.40mm) |
| Case / Size | Nonstandard |
| Supplier | Pulse Electronics |
| Description | FIXED IND 6.8UH 2.7A 66.3 MOHM |
| Series | BPSS |
| productStatus | Active |
| typeConstruction | - |
| coreMaterial | - |
| shielding | Shielded |
| qFactor | - |
| selfResonantFreq | - |
| ratings | - |
| testFrequency | 100 kHz |
| mountingType | Surface Mount |
| supplierDevicePackage | - |
| heightMax | 0.098" (2.50mm) |
| features | - |
