BPSS00080740121T00
Pulse Electronics
Description
FIXED IND 120UH 890MA 560 MOHM
Specifications
Parameter Guide
Understand the key electrical and mechanical specifications for BPSS00080740121T00.
BPSS00080740121T00 has an inductance value of 120 µH. This value indicates how much magnetic energy the component can store and is one of the first parameters to compare when selecting an inductor.
BPSS00080740121T00 is rated for 890 mA. Current rating helps determine whether the part can carry the expected DC or RMS current without excessive heating or saturation risk.
BPSS00080740121T00 lists a DC resistance of 560mOhm Max. Lower DCR usually reduces conduction loss and improves efficiency in power circuits.
BPSS00080740121T00 uses a package or case of Nonstandard. Package size affects PCB footprint, height clearance, thermal behavior, and compatibility with automated assembly.
Explore Related Datasheet Paths
Continue from BPSS00080740121T00 to manufacturer, series, and broader datasheet collections.
Similar-specification candidates · Engineering review required
Screened against recorded construction, core, mounting, dimensions and current/DCR. Land pattern, test conditions and circuit compatibility still require validation.
Missing evidence or no candidates passed screening. A replacement cannot be determined; request a review of the original datasheets.
Product Attributes
| Inductance | 120 µH |
| Tolerance | ±30% |
| Current Rating | 890 mA |
| DC Resistance (DCR) | 560mOhm Max |
| Saturation Current | 1A |
| Operating Temperature | -40°C ~ 105°C |
| Dimensions | 0.362" L x 0.291" W (9.20mm x 7.40mm) |
| Case / Size | Nonstandard |
| Package / Case | Nonstandard |
| Supplier | Pulse Electronics |
| Description | FIXED IND 120UH 890MA 560 MOHM |
| Series | BPSS |
| Product Status | Active |
| Shielding | Shielded |
| Inductance Test Frequency | 100 kHz |
| Mounting Type | Surface Mount |
| Height - Seated (Max) | 0.157" (4.00mm) |
