BPSS00080740680M00
Pulse Electronics
Description
FIXED IND 68UH 1.2A 310 MOHM SMD
Specifications
Parameter Guide
Understand the key electrical and mechanical specifications for BPSS00080740680M00.
BPSS00080740680M00 has an inductance value of 68 µH. This value indicates how much magnetic energy the component can store and is one of the first parameters to compare when selecting an inductor.
BPSS00080740680M00 is rated for 1.2 A. Current rating helps determine whether the part can carry the expected DC or RMS current without excessive heating or saturation risk.
BPSS00080740680M00 lists a DC resistance of 310mOhm Max. Lower DCR usually reduces conduction loss and improves efficiency in power circuits.
BPSS00080740680M00 uses a package or case of Nonstandard. Package size affects PCB footprint, height clearance, thermal behavior, and compatibility with automated assembly.
Explore Related Datasheet Paths
Continue from BPSS00080740680M00 to manufacturer, series, and broader datasheet collections.
Similar-specification candidates · Engineering review required
Screened against recorded construction, core, mounting, dimensions and current/DCR. Land pattern, test conditions and circuit compatibility still require validation.
Missing evidence or no candidates passed screening. A replacement cannot be determined; request a review of the original datasheets.
Product Attributes
| Inductance | 68 µH |
| Tolerance | ±20% |
| Current Rating | 1.2 A |
| DC Resistance (DCR) | 310mOhm Max |
| Saturation Current | 1.36A |
| Operating Temperature | -40°C ~ 105°C |
| Dimensions | 0.362" L x 0.291" W (9.20mm x 7.40mm) |
| Case / Size | Nonstandard |
| Package / Case | Nonstandard |
| Supplier | Pulse Electronics |
| Description | FIXED IND 68UH 1.2A 310 MOHM SMD |
| Series | BPSS |
| Product Status | Active |
| Shielding | Shielded |
| Inductance Test Frequency | 100 kHz |
| Mounting Type | Surface Mount |
| Height - Seated (Max) | 0.157" (4.00mm) |
