Description
FIXED IND 68UH 1.2A 310 MOHM SMD
Specifications
Inductance
68 µH
Current Rating
1.2 A
DC Resistance (DCR)
310mOhm Max
Dimensions
0.362" L x 0.291" W (9.20mm x 7.40mm)
Product Attributes
Manufacturer Verified
Last verified: 6/18/2026| Inductance | 68 µH |
| Tolerance | ±30% |
| Current Rating | 1.2 A |
| DC Resistance (DCR) | 310mOhm Max |
| saturationCurrent | 1.36A |
| Operating Temperature | -40°C ~ 105°C |
| Dimensions | 0.362" L x 0.291" W (9.20mm x 7.40mm) |
| Case / Size | Nonstandard |
| Supplier | Pulse Electronics |
| Description | FIXED IND 68UH 1.2A 310 MOHM SMD |
| Series | BPSS |
| productStatus | Active |
| typeConstruction | - |
| coreMaterial | - |
| shielding | Shielded |
| qFactor | - |
| selfResonantFreq | - |
| ratings | - |
| testFrequency | 100 kHz |
| mountingType | Surface Mount |
| supplierDevicePackage | - |
| heightMax | 0.157" (4.00mm) |
| features | - |
