Description
FIXED IND 15NH 220MA 890 MOHM
Specifications
Parameter Guide
Understand the key electrical and mechanical specifications for BSCQ0006030315NH00.
BSCQ0006030315NH00 has an inductance value of 15 nH. This value indicates how much magnetic energy the component can store and is one of the first parameters to compare when selecting an inductor.
BSCQ0006030315NH00 is rated for 220 mA. Current rating helps determine whether the part can carry the expected DC or RMS current without excessive heating or saturation risk.
BSCQ0006030315NH00 lists a DC resistance of 890mOhm Max. Lower DCR usually reduces conduction loss and improves efficiency in power circuits.
BSCQ0006030315NH00 uses a package or case of 0201 (0603 Metric). Package size affects PCB footprint, height clearance, thermal behavior, and compatibility with automated assembly.
Explore Related Datasheet Paths
Continue from BSCQ0006030315NH00 to manufacturer, series, and broader datasheet collections.
Product Attributes
| Inductance | 15 nH |
| Tolerance | ±3% |
| Current Rating | 220 mA |
| DC Resistance (DCR) | 890mOhm Max |
| Operating Temperature | -55°C ~ 125°C |
| Dimensions | 0.024" L x 0.012" W (0.60mm x 0.30mm) |
| Case / Size | 0201 (0603 Metric) |
| Package / Case | 0201 (0603 Metric) |
| Supplier | Pulse Electronics |
| Description | FIXED IND 15NH 220MA 890 MOHM |
| Series | BSCQ |
| Product Status | Active |
| Type / Construction | Multilayer |
| Core Material | Ceramic |
| Shielding | Unshielded |
| Q @ Frequency | 14 @ 500MHz |
| Self Resonant Frequency | 2.6GHz |
| Inductance Test Frequency | 500 MHz |
| Mounting Type | Surface Mount |
| Supplier Device Package | 0201 |
| Height - Seated (Max) | 0.013" (0.33mm) |
