Description
FIXED IND 51NH 660MA 280 MOHM
Specifications
Parameter Guide
Understand the key electrical and mechanical specifications for BWHP0016100851NH00.
BWHP0016100851NH00 has an inductance value of 51 nH. This value indicates how much magnetic energy the component can store and is one of the first parameters to compare when selecting an inductor.
BWHP0016100851NH00 is rated for 660 mA. Current rating helps determine whether the part can carry the expected DC or RMS current without excessive heating or saturation risk.
BWHP0016100851NH00 lists a DC resistance of 280mOhm Max. Lower DCR usually reduces conduction loss and improves efficiency in power circuits.
BWHP0016100851NH00 uses a package or case of 0603 (1608 Metric). Package size affects PCB footprint, height clearance, thermal behavior, and compatibility with automated assembly.
Explore Related Datasheet Paths
Continue from BWHP0016100851NH00 to manufacturer, series, and broader datasheet collections.
Alternative Solutions
Compare possible alternatives with similar specifications. Verify every electrical and mechanical requirement before use.
Product Attributes
| Inductance | 51 nH |
| Tolerance | ±3% |
| Current Rating | 660 mA |
| DC Resistance (DCR) | 280mOhm Max |
| Operating Temperature | -40°C ~ 125°C |
| Dimensions | 0.063" L x 0.039" W (1.60mm x 1.00mm) |
| Case / Size | 0603 (1608 Metric) |
| Package / Case | 0603 (1608 Metric) |
| Supplier | Pulse Electronics |
| Description | FIXED IND 51NH 660MA 280 MOHM |
| Series | BWHP |
| Product Status | Active |
| Type / Construction | Drum Core, Wirewound |
| Core Material | Ceramic |
| Shielding | Unshielded |
| Q @ Frequency | 42 @ 250MHz |
| Self Resonant Frequency | 2.3GHz |
| Inductance Test Frequency | 200 MHz |
| Mounting Type | Surface Mount |
| Supplier Device Package | 0603 |
| Height - Seated (Max) | 0.040" (1.02mm) |
