FIXED IND 1.5UH 1.3A 130 MOHM
| Inductance | 1.5 µH |
| Tolerance | ±20% |
| Current Rating | 1.3 A |
| DC Resistance (DCR) | 130mOhm |
| saturationCurrent | 1.44A |
| Operating Temperature | -55°C ~ 125°C |
| Dimensions | 0.079" L x 0.063" W (2.00mm x 1.60mm) |
| Case / Size | 0806 (2016 Metric) |
| Supplier | Pulse Electronics |
| Description | FIXED IND 1.5UH 1.3A 130 MOHM |
| Series | BWVF |
| productStatus | Active |
| typeConstruction | - |
| coreMaterial | Ferrite |
| shielding | Shielded |
| qFactor | - |
| selfResonantFreq | - |
| ratings | - |
| testFrequency | 1 MHz |
| mountingType | Surface Mount |
| supplierDevicePackage | 0806 |
| heightMax | 0.049" (1.25mm) |
| features | - |
