FIXED IND 1.5UH 3.33A 35 MOHM
| Inductance | 1.5 µH |
| Tolerance | ±30% |
| Current Rating | 3.33 A |
| DC Resistance (DCR) | 35mOhm |
| saturationCurrent | 3.78A |
| Operating Temperature | -55°C ~ 125°C |
| Dimensions | 0.157" L x 0.157" W (4.00mm x 4.00mm) |
| Case / Size | 1616 (4040 Metric) |
| Supplier | Pulse Electronics |
| Description | FIXED IND 1.5UH 3.33A 35 MOHM |
| Series | BWVF |
| productStatus | Active |
| typeConstruction | - |
| coreMaterial | Ferrite |
| shielding | Shielded |
| qFactor | - |
| selfResonantFreq | - |
| ratings | - |
| testFrequency | 100 kHz |
| mountingType | Surface Mount |
| supplierDevicePackage | 1616 |
| heightMax | 0.110" (2.80mm) |
| features | - |
