FIXED IND 3.3UH 1.5A 135 MOHM
| Inductance | 3.3 µH |
| Tolerance | ±30% |
| Current Rating | 1.5 A |
| DC Resistance (DCR) | 135mOhm |
| saturationCurrent | 1.6A |
| Operating Temperature | -55°C ~ 125°C |
| Dimensions | 0.232" L x 0.220" W (5.90mm x 5.60mm) |
| Case / Size | Nonstandard |
| Supplier | Pulse Electronics |
| Description | FIXED IND 3.3UH 1.5A 135 MOHM |
| Series | BWVH |
| productStatus | Active |
| typeConstruction | - |
| coreMaterial | - |
| shielding | Shielded |
| qFactor | - |
| selfResonantFreq | - |
| ratings | - |
| testFrequency | 1 MHz |
| mountingType | Surface Mount |
| supplierDevicePackage | - |
| heightMax | 0.039" (1.00mm) |
| features | - |
