Description
FIXED IND 33NH 1A 140 MOHM SMD
Specifications
Parameter Guide
Understand the key electrical and mechanical specifications for CC1008-033G.
CC1008-033G has an inductance value of 33 nH. This value indicates how much magnetic energy the component can store and is one of the first parameters to compare when selecting an inductor.
CC1008-033G is rated for 1 A. Current rating helps determine whether the part can carry the expected DC or RMS current without excessive heating or saturation risk.
CC1008-033G lists a DC resistance of 140mOhm Max. Lower DCR usually reduces conduction loss and improves efficiency in power circuits.
CC1008-033G uses a package or case of Nonstandard. Package size affects PCB footprint, height clearance, thermal behavior, and compatibility with automated assembly.
Explore Related Datasheet Paths
Continue from CC1008-033G to manufacturer, series, and broader datasheet collections.
Product Attributes
| Inductance | 33 nH |
| Tolerance | ±2% |
| Current Rating | 1 A |
| DC Resistance (DCR) | 140mOhm Max |
| Operating Temperature | -40°C ~ 125°C |
| Dimensions | 0.115" L x 0.110" W (2.92mm x 2.79mm) |
| Case / Size | Nonstandard |
| Package / Case | Nonstandard |
| Supplier | Gowanda |
| Description | FIXED IND 33NH 1A 140 MOHM SMD |
| Series | CC1008 |
| Product Status | Active |
| Type / Construction | Wirewound |
| Core Material | Ceramic |
| Shielding | Unshielded |
| Q @ Frequency | 60 @ 50MHz |
| Self Resonant Frequency | 1.6GHz |
| Inductance Test Frequency | 50 MHz |
| Mounting Type | Surface Mount |
| Height - Seated (Max) | 0.090" (2.29mm) |
