Description
FIXED IND 680NH 200MA 1.47 OHM
Specifications
Parameter Guide
Understand the key electrical and mechanical specifications for CL1008-2684JQL1T-1.
CL1008-2684JQL1T-1 has an inductance value of 680 nH. This value indicates how much magnetic energy the component can store and is one of the first parameters to compare when selecting an inductor.
CL1008-2684JQL1T-1 is rated for 200 mA. Current rating helps determine whether the part can carry the expected DC or RMS current without excessive heating or saturation risk.
CL1008-2684JQL1T-1 lists a DC resistance of 1.47Ohm Max. Lower DCR usually reduces conduction loss and improves efficiency in power circuits.
CL1008-2684JQL1T-1 uses a package or case of Nonstandard. Package size affects PCB footprint, height clearance, thermal behavior, and compatibility with automated assembly.
Explore Related Datasheet Paths
Continue from CL1008-2684JQL1T-1 to manufacturer, series, and broader datasheet collections.
Product Attributes
| Inductance | 680 nH |
| Tolerance | ±5% |
| Current Rating | 200 mA |
| DC Resistance (DCR) | 1.47Ohm Max |
| Saturation Current | - |
| Operating Temperature | -55°C ~ 125°C |
| Dimensions | 0.110 L x 0.102 W (2.80mm x 2.60mm) |
| Case / Size | Nonstandard |
| Package / Case | Nonstandard |
| Supplier | Knowles Voltronics |
| Description | FIXED IND 680NH 200MA 1.47 OHM |
| Series | CL |
| Product Status | Discontinued at DigiKey |
| Type / Construction | Wirewound |
| Core Material | Ceramic |
| Shielding | Unshielded |
| Q @ Frequency | 45 @ 100MHz |
| Self Resonant Frequency | 375MHz |
| Ratings | - |
| Inductance Test Frequency | 25 MHz |
| Mounting Type | Surface Mount |
| Supplier Device Package | 1008 |
| Height - Seated (Max) | 0.106 (2.70mm) |
| Features | - |
