Description
FIXED IND 2.5UH 1.7A 80 MOHM TH
Specifications
Parameter Guide
Understand the key electrical and mechanical specifications for CTS5F-2R5K.
CTS5F-2R5K has an inductance value of 2.5 µH. This value indicates how much magnetic energy the component can store and is one of the first parameters to compare when selecting an inductor.
CTS5F-2R5K is rated for 1.7 A. Current rating helps determine whether the part can carry the expected DC or RMS current without excessive heating or saturation risk.
CTS5F-2R5K lists a DC resistance of 80mOhm Max. Lower DCR usually reduces conduction loss and improves efficiency in power circuits.
CTS5F-2R5K uses a package or case of Axial. Package size affects PCB footprint, height clearance, thermal behavior, and compatibility with automated assembly.
Explore Related Datasheet Paths
Continue from CTS5F-2R5K to manufacturer, series, and broader datasheet collections.
Product Attributes
| Inductance | 2.5 µH |
| Tolerance | ±10% |
| Current Rating | 1.7 A |
| DC Resistance (DCR) | 80mOhm Max |
| Saturation Current | - |
| Operating Temperature | -55°C ~ 105°C |
| Dimensions | 0.150 Dia x 0.449 L (3.81mm x 11.40mm) |
| Case / Size | Axial |
| Package / Case | Axial |
| Supplier | Central Technologies |
| Description | FIXED IND 2.5UH 1.7A 80 MOHM TH |
| Series | CTS5F |
| Product Status | Active |
| Type / Construction | Molded |
| Core Material | - |
| Shielding | Shielded |
| Q @ Frequency | 45 @ 7.9MHz |
| Self Resonant Frequency | 115MHz |
| Ratings | - |
| Inductance Test Frequency | 7.9 MHz |
| Mounting Type | Through Hole |
| Supplier Device Package | Axial |
| Height - Seated (Max) | - |
| Features | - |
