Description
FIXED IND 2.2MH 800MA 1.149 OHM
Specifications
Parameter Guide
Understand the key electrical and mechanical specifications for DB2-224.
DB2-224 has an inductance value of 2.2 mH. This value indicates how much magnetic energy the component can store and is one of the first parameters to compare when selecting an inductor.
DB2-224 is rated for 800 mA. Current rating helps determine whether the part can carry the expected DC or RMS current without excessive heating or saturation risk.
DB2-224 lists a DC resistance of 1.149Ohm Max. Lower DCR usually reduces conduction loss and improves efficiency in power circuits.
DB2-224 uses a package or case of Radial, Vertical Cylinder (Open). Package size affects PCB footprint, height clearance, thermal behavior, and compatibility with automated assembly.
Explore Related Datasheet Paths
Continue from DB2-224 to manufacturer, series, and broader datasheet collections.
Product Attributes
| Inductance | 2.2 mH |
| Tolerance | ±10% |
| Current Rating | 800 mA |
| DC Resistance (DCR) | 1.149Ohm Max |
| Saturation Current | 2A |
| Operating Temperature | -55°C ~ 125°C |
| Dimensions | 0.800" Dia (20.32mm) |
| Case / Size | Radial, Vertical Cylinder (Open) |
| Package / Case | Radial, Vertical Cylinder (Open) |
| Supplier | Gowanda |
| Description | FIXED IND 2.2MH 800MA 1.149 OHM |
| Series | DB2 |
| Product Status | Active |
| Type / Construction | Wirewound |
| Core Material | Ferrite |
| Shielding | Unshielded |
| Inductance Test Frequency | 1 kHz |
| Mounting Type | Through Hole |
| Supplier Device Package | Radial |
| Height - Seated (Max) | 0.712" (18.08mm) |
