Description
FIXED IND 39NH 320MA 550 MOHM
Specifications
Parameter Guide
Understand the key electrical and mechanical specifications for HBWS1005-39NJ.
HBWS1005-39NJ has an inductance value of 39 nH. This value indicates how much magnetic energy the component can store and is one of the first parameters to compare when selecting an inductor.
HBWS1005-39NJ is rated for 320 mA. Current rating helps determine whether the part can carry the expected DC or RMS current without excessive heating or saturation risk.
HBWS1005-39NJ lists a DC resistance of 550mOhm Max. Lower DCR usually reduces conduction loss and improves efficiency in power circuits.
HBWS1005-39NJ uses a package or case of 0402 (1005 Metric). Package size affects PCB footprint, height clearance, thermal behavior, and compatibility with automated assembly.
Explore Related Datasheet Paths
Continue from HBWS1005-39NJ to manufacturer, series, and broader datasheet collections.
Product Attributes
| Inductance | 39 nH |
| Tolerance | ±5% |
| Current Rating | 320 mA |
| DC Resistance (DCR) | 550mOhm Max |
| Saturation Current | - |
| Operating Temperature | -40°C ~ 125°C |
| Dimensions | 0.039" L x 0.022" W (1.00mm x 0.55mm) |
| Case / Size | 0402 (1005 Metric) |
| Package / Case | 0402 (1005 Metric) |
| Supplier | Max Echo |
| Description | FIXED IND 39NH 320MA 550 MOHM |
| Series | HBWS |
| Product Status | Active |
| Type / Construction | Wirewound |
| Core Material | Ceramic |
| Shielding | Unshielded |
| Q @ Frequency | 25 @ 250MHz |
| Self Resonant Frequency | 2.1GHz |
| Ratings | - |
| Inductance Test Frequency | 250 MHz |
| Mounting Type | Surface Mount |
| Supplier Device Package | 0402 (1005 Metric) |
| Height - Seated (Max) | 0.020" (0.50mm) |
