Description
FIXED IND 33NH 120MA 1.8 OHM SMD
Specifications
Parameter Guide
Understand the key electrical and mechanical specifications for HCI0603FQ-33NJ-MS8.
HCI0603FQ-33NJ-MS8 has an inductance value of 33 nH. This value indicates how much magnetic energy the component can store and is one of the first parameters to compare when selecting an inductor.
HCI0603FQ-33NJ-MS8 is rated for 120 mA. Current rating helps determine whether the part can carry the expected DC or RMS current without excessive heating or saturation risk.
HCI0603FQ-33NJ-MS8 lists a DC resistance of 1.8Ohm Max. Lower DCR usually reduces conduction loss and improves efficiency in power circuits.
HCI0603FQ-33NJ-MS8 uses a package or case of 0201 (0603 Metric). Package size affects PCB footprint, height clearance, thermal behavior, and compatibility with automated assembly.
Explore Related Datasheet Paths
Continue from HCI0603FQ-33NJ-MS8 to manufacturer, series, and broader datasheet collections.
Product Attributes
| Inductance | 33 nH |
| Tolerance | ±5% |
| Current Rating | 120 mA |
| DC Resistance (DCR) | 1.8Ohm Max |
| Operating Temperature | -55°C ~ 105°C |
| Dimensions | 0.024" L x 0.012" W (0.60mm x 0.30mm) |
| Case / Size | 0201 (0603 Metric) |
| Package / Case | 0201 (0603 Metric) |
| Supplier | TAI-TECH |
| Description | FIXED IND 33NH 120MA 1.8 OHM SMD |
| Series | HCI0603FQ-MS8 |
| Product Status | Active |
| Type / Construction | Multilayer |
| Shielding | Unshielded |
| Q @ Frequency | 12 @ 300MHz |
| Self Resonant Frequency | 1.8GHz |
| Inductance Test Frequency | 300 MHz |
| Mounting Type | Surface Mount |
| Supplier Device Package | 0201 |
| Height - Seated (Max) | 0.013" (0.33mm) |
