Description
FIXED IND 30NH 120MA 2.8 OHM SMD
Specifications
Parameter Guide
Understand the key electrical and mechanical specifications for HKQ040230NH-E.
HKQ040230NH-E has an inductance value of 30 nH. This value indicates how much magnetic energy the component can store and is one of the first parameters to compare when selecting an inductor.
HKQ040230NH-E is rated for 120 mA. Current rating helps determine whether the part can carry the expected DC or RMS current without excessive heating or saturation risk.
HKQ040230NH-E lists a DC resistance of 2.8Ohm Max. Lower DCR usually reduces conduction loss and improves efficiency in power circuits.
HKQ040230NH-E uses a package or case of 01005 (0402 Metric). Package size affects PCB footprint, height clearance, thermal behavior, and compatibility with automated assembly.
Explore Related Datasheet Paths
Continue from HKQ040230NH-E to manufacturer, series, and broader datasheet collections.
Product Attributes
| Inductance | 30 nH |
| Tolerance | ±3% |
| Current Rating | 120 mA |
| DC Resistance (DCR) | 2.8Ohm Max |
| Operating Temperature | -55°C ~ 125°C |
| Dimensions | 0.016" L x 0.008" W (0.40mm x 0.20mm) |
| Case / Size | 01005 (0402 Metric) |
| Package / Case | 01005 (0402 Metric) |
| Supplier | Taiyo Yuden |
| Description | FIXED IND 30NH 120MA 2.8 OHM SMD |
| Series | HK, Q Type |
| Product Status | Obsolete |
| Type / Construction | Multilayer |
| Core Material | Ceramic |
| Shielding | Unshielded |
| Q @ Frequency | 11 @ 500MHz |
| Self Resonant Frequency | 1.7GHz |
| Inductance Test Frequency | 100 MHz |
| Mounting Type | Surface Mount |
| Supplier Device Package | 01005 (0402 Metric) |
| Height - Seated (Max) | 0.009" (0.23mm) |
