Description
FIXED IND 6.8UH 1.85A 48 MOHM
Specifications
Parameter Guide
Understand the key electrical and mechanical specifications for IFDC2020CZER6R8N.
IFDC2020CZER6R8N has an inductance value of 6.8 µH. This value indicates how much magnetic energy the component can store and is one of the first parameters to compare when selecting an inductor.
IFDC2020CZER6R8N is rated for 1.85 A. Current rating helps determine whether the part can carry the expected DC or RMS current without excessive heating or saturation risk.
IFDC2020CZER6R8N lists a DC resistance of 48mOhm Max. Lower DCR usually reduces conduction loss and improves efficiency in power circuits.
IFDC2020CZER6R8N uses a package or case of Nonstandard. Package size affects PCB footprint, height clearance, thermal behavior, and compatibility with automated assembly.
Explore Related Datasheet Paths
Continue from IFDC2020CZER6R8N to manufacturer, series, and broader datasheet collections.
Alternative Solutions
Compare possible alternatives with similar specifications. Verify every electrical and mechanical requirement before use.
Product Attributes
| Inductance | 6.8 µH |
| Tolerance | ±30% |
| Current Rating | 1.85 A |
| DC Resistance (DCR) | 48mOhm Max |
| Operating Temperature | -40°C ~ 105°C |
| Dimensions | 0.236" L x 0.236" W (6.00mm x 6.00mm) |
| Case / Size | Nonstandard |
| Package / Case | Nonstandard |
| Supplier | Vishay Dale |
| Description | FIXED IND 6.8UH 1.85A 48 MOHM |
| Series | IFDC-2020CZ |
| Product Status | Active |
| Type / Construction | Drum Core, Wirewound |
| Core Material | Ferrite |
| Shielding | Shielded |
| Inductance Test Frequency | 100 kHz |
| Mounting Type | Surface Mount |
| Height - Seated (Max) | 0.118" (3.00mm) |
