Description
FIXED IND 72NH 45A 0.35 MOHM SMD
Specifications
Parameter Guide
Understand the key electrical and mechanical specifications for IFLR2727EZER72NM01.
IFLR2727EZER72NM01 has an inductance value of 72 nH. This value indicates how much magnetic energy the component can store and is one of the first parameters to compare when selecting an inductor.
IFLR2727EZER72NM01 is rated for 45 A. Current rating helps determine whether the part can carry the expected DC or RMS current without excessive heating or saturation risk.
IFLR2727EZER72NM01 lists a DC resistance of 0.35mOhm Max. Lower DCR usually reduces conduction loss and improves efficiency in power circuits.
IFLR2727EZER72NM01 uses a package or case of 2-SMD, J-Lead. Package size affects PCB footprint, height clearance, thermal behavior, and compatibility with automated assembly.
Explore Related Datasheet Paths
Continue from IFLR2727EZER72NM01 to manufacturer, series, and broader datasheet collections.
Product Attributes
| Inductance | 72 nH |
| Tolerance | ±20% |
| Current Rating | 45 A |
| DC Resistance (DCR) | 0.35mOhm Max |
| Saturation Current | 58A |
| Operating Temperature | -40°C ~ 125°C |
| Dimensions | 0.276" L x 0.276" W (7.00mm x 7.00mm) |
| Case / Size | 2-SMD, J-Lead |
| Package / Case | 2-SMD, J-Lead |
| Supplier | Vishay Dale |
| Description | FIXED IND 72NH 45A 0.35 MOHM SMD |
| Series | IFLR-2727EZ-01 |
| Product Status | Active |
| Type / Construction | - |
| Core Material | - |
| Shielding | Shielded |
| Q @ Frequency | - |
| Self Resonant Frequency | - |
| Ratings | - |
| Inductance Test Frequency | 100 kHz |
| Mounting Type | Surface Mount |
| Supplier Device Package | - |
| Height - Seated (Max) | 0.197" (5.00mm) |
| Features | - |
