Description
FIXED IND 33UH 3.7A 117.7 MOHM
Specifications
Parameter Guide
Understand the key electrical and mechanical specifications for IHLE4040DDER330M5A.
IHLE4040DDER330M5A has an inductance value of 33 µH. This value indicates how much magnetic energy the component can store and is one of the first parameters to compare when selecting an inductor.
IHLE4040DDER330M5A is rated for 3.7 A. Current rating helps determine whether the part can carry the expected DC or RMS current without excessive heating or saturation risk.
IHLE4040DDER330M5A lists a DC resistance of 117.7mOhm Max. Lower DCR usually reduces conduction loss and improves efficiency in power circuits.
IHLE4040DDER330M5A uses a package or case of 4-SMD. Package size affects PCB footprint, height clearance, thermal behavior, and compatibility with automated assembly.
Explore Related Datasheet Paths
Continue from IHLE4040DDER330M5A to manufacturer, series, and broader datasheet collections.
Product Attributes
| Inductance | 33 µH |
| Tolerance | ±20% |
| Current Rating | 3.7 A |
| DC Resistance (DCR) | 117.7mOhm Max |
| Saturation Current | 4.2A |
| Operating Temperature | -55°C ~ 155°C |
| Dimensions | 0.426" L x 0.426" W (10.82mm x 10.82mm) |
| Case / Size | 4-SMD |
| Package / Case | 4-SMD |
| Supplier | Vishay Dale |
| Description | FIXED IND 33UH 3.7A 117.7 MOHM |
| Series | IHLE-4040DD-5A |
| Product Status | Active |
| Type / Construction | Wirewound |
| Core Material | - |
| Shielding | Shielded |
| Q @ Frequency | - |
| Self Resonant Frequency | - |
| Ratings | AEC-Q200 |
| Inductance Test Frequency | 100 kHz |
| Mounting Type | Surface Mount |
| Supplier Device Package | - |
| Height - Seated (Max) | 0.169" (4.30mm) |
| Features | - |
