Description
FIXED IND 3.3UH 11A 11.81 MOHM
Specifications
Parameter Guide
Understand the key electrical and mechanical specifications for IHLE4040DDER3R3M5A.
IHLE4040DDER3R3M5A has an inductance value of 3.3 µH. This value indicates how much magnetic energy the component can store and is one of the first parameters to compare when selecting an inductor.
IHLE4040DDER3R3M5A is rated for 11 A. Current rating helps determine whether the part can carry the expected DC or RMS current without excessive heating or saturation risk.
IHLE4040DDER3R3M5A lists a DC resistance of 11.81mOhm Max. Lower DCR usually reduces conduction loss and improves efficiency in power circuits.
IHLE4040DDER3R3M5A uses a package or case of 4-SMD. Package size affects PCB footprint, height clearance, thermal behavior, and compatibility with automated assembly.
Explore Related Datasheet Paths
Continue from IHLE4040DDER3R3M5A to manufacturer, series, and broader datasheet collections.
Product Attributes
| Inductance | 3.3 µH |
| Tolerance | ±20% |
| Current Rating | 11 A |
| DC Resistance (DCR) | 11.81mOhm Max |
| Saturation Current | 12A |
| Operating Temperature | -55°C ~ 155°C |
| Dimensions | 0.426" L x 0.426" W (10.82mm x 10.82mm) |
| Case / Size | 4-SMD |
| Package / Case | 4-SMD |
| Supplier | Vishay Dale |
| Description | FIXED IND 3.3UH 11A 11.81 MOHM |
| Series | IHLE-4040DD-5A |
| Product Status | Active |
| Type / Construction | Wirewound |
| Core Material | - |
| Shielding | Shielded |
| Q @ Frequency | - |
| Self Resonant Frequency | - |
| Ratings | AEC-Q200 |
| Inductance Test Frequency | 100 kHz |
| Mounting Type | Surface Mount |
| Supplier Device Package | - |
| Height - Seated (Max) | 0.169" (4.30mm) |
| Features | - |
