Description
FIXED IND 0.39NH 550MA 100 MOHM
Specifications
Parameter Guide
Understand the key electrical and mechanical specifications for L0201R39AHSTR\500.
L0201R39AHSTR\500 has an inductance value of 0.39 nH. This value indicates how much magnetic energy the component can store and is one of the first parameters to compare when selecting an inductor.
L0201R39AHSTR\500 is rated for 550 mA. Current rating helps determine whether the part can carry the expected DC or RMS current without excessive heating or saturation risk.
L0201R39AHSTR\500 lists a DC resistance of 100mOhm Max. Lower DCR usually reduces conduction loss and improves efficiency in power circuits.
L0201R39AHSTR\500 uses a package or case of 0201 (0603 Metric). Package size affects PCB footprint, height clearance, thermal behavior, and compatibility with automated assembly.
Explore Related Datasheet Paths
Continue from L0201R39AHSTR\500 to manufacturer, series, and broader datasheet collections.
Product Attributes
| Inductance | 0.39 nH |
| Tolerance | ±0.05nH |
| Current Rating | 550 mA |
| DC Resistance (DCR) | 100mOhm Max |
| Saturation Current | - |
| Operating Temperature | -55°C ~ 125°C |
| Dimensions | 0.024 L x 0.012 W (0.60mm x 0.30mm) |
| Case / Size | 0201 (0603 Metric) |
| Package / Case | 0201 (0603 Metric) |
| Supplier | KYOCERA AVX |
| Description | FIXED IND 0.39NH 550MA 100 MOHM |
| Series | Accu-L® |
| Product Status | Active |
| Type / Construction | Thin Film |
| Core Material | Non-Magnetic |
| Shielding | Unshielded |
| Q @ Frequency | 11 @ 450MHz |
| Self Resonant Frequency | 33GHz |
| Ratings | - |
| Inductance Test Frequency | 450 MHz |
| Mounting Type | Surface Mount |
| Supplier Device Package | 0201 (0603 Metric) |
| Height - Seated (Max) | 0.011 (0.28mm) |
| Features | - |
