Description
FIXED IND 0.82NH 500MA 60 MOHM
Specifications
Parameter Guide
Understand the key electrical and mechanical specifications for L0402R82BHNTR.
L0402R82BHNTR has an inductance value of 0.82 nH. This value indicates how much magnetic energy the component can store and is one of the first parameters to compare when selecting an inductor.
L0402R82BHNTR is rated for 500 mA. Current rating helps determine whether the part can carry the expected DC or RMS current without excessive heating or saturation risk.
L0402R82BHNTR lists a DC resistance of 60mOhm Max. Lower DCR usually reduces conduction loss and improves efficiency in power circuits.
L0402R82BHNTR uses a package or case of 0402 (1005 Metric). Package size affects PCB footprint, height clearance, thermal behavior, and compatibility with automated assembly.
Explore Related Datasheet Paths
Continue from L0402R82BHNTR to manufacturer, series, and broader datasheet collections.
Product Attributes
| Inductance | 0.82 nH |
| Tolerance | ±0.1nH |
| Current Rating | 500 mA |
| DC Resistance (DCR) | 60mOhm Max |
| Saturation Current | - |
| Operating Temperature | - |
| Dimensions | 0.039 L x 0.023 W (1.00mm x 0.58mm) |
| Case / Size | 0402 (1005 Metric) |
| Package / Case | 0402 (1005 Metric) |
| Supplier | KYOCERA AVX |
| Description | FIXED IND 0.82NH 500MA 60 MOHM |
| Series | Accu-L® 0402 |
| Product Status | Active |
| Type / Construction | Thin Film |
| Core Material | Non-Magnetic |
| Shielding | Unshielded |
| Q @ Frequency | 25 @ 450MHz |
| Self Resonant Frequency | 20GHz |
| Ratings | - |
| Inductance Test Frequency | 450 MHz |
| Mounting Type | Surface Mount |
| Supplier Device Package | 0402 (1005 Metric) |
| Height - Seated (Max) | 0.018 (0.45mm) |
| Features | - |
