Description
FIXED IND 180UH 165MA 4.6 OHM TH
Specifications
Parameter Guide
Understand the key electrical and mechanical specifications for LAL04NA181K.
LAL04NA181K has an inductance value of 180 µH. This value indicates how much magnetic energy the component can store and is one of the first parameters to compare when selecting an inductor.
LAL04NA181K is rated for 165 mA. Current rating helps determine whether the part can carry the expected DC or RMS current without excessive heating or saturation risk.
LAL04NA181K lists a DC resistance of 4.6Ohm Max. Lower DCR usually reduces conduction loss and improves efficiency in power circuits.
LAL04NA181K uses a package or case of Axial. Package size affects PCB footprint, height clearance, thermal behavior, and compatibility with automated assembly.
Explore Related Datasheet Paths
Continue from LAL04NA181K to manufacturer, series, and broader datasheet collections.
Product Attributes
| Inductance | 180 µH |
| Tolerance | ±10% |
| Current Rating | 165 mA |
| DC Resistance (DCR) | 4.6Ohm Max |
| Operating Temperature | -25°C ~ 105°C |
| Dimensions | 0.157" Dia x 0.386" L (4.00mm x 9.80mm) |
| Case / Size | Axial |
| Package / Case | Axial |
| Supplier | Taiyo Yuden |
| Description | FIXED IND 180UH 165MA 4.6 OHM TH |
| Series | LA, L Type |
| Product Status | Obsolete |
| Shielding | Unshielded |
| Q @ Frequency | 50 @ 796kHz |
| Self Resonant Frequency | 3.3MHz |
| Inductance Test Frequency | 796 kHz |
| Mounting Type | Through Hole |
