Description
FIXED IND 1.2UH 880MA 210 MOHM
Specifications
Parameter Guide
Understand the key electrical and mechanical specifications for LAL04NA1R2M.
LAL04NA1R2M has an inductance value of 1.2 µH. This value indicates how much magnetic energy the component can store and is one of the first parameters to compare when selecting an inductor.
LAL04NA1R2M is rated for 880 mA. Current rating helps determine whether the part can carry the expected DC or RMS current without excessive heating or saturation risk.
LAL04NA1R2M lists a DC resistance of 210mOhm Max. Lower DCR usually reduces conduction loss and improves efficiency in power circuits.
LAL04NA1R2M uses a package or case of Axial. Package size affects PCB footprint, height clearance, thermal behavior, and compatibility with automated assembly.
Explore Related Datasheet Paths
Continue from LAL04NA1R2M to manufacturer, series, and broader datasheet collections.
Product Attributes
| Inductance | 1.2 µH |
| Tolerance | ±20% |
| Current Rating | 880 mA |
| DC Resistance (DCR) | 210mOhm Max |
| Operating Temperature | -25°C ~ 105°C |
| Dimensions | 0.157" Dia x 0.386" L (4.00mm x 9.80mm) |
| Case / Size | Axial |
| Package / Case | Axial |
| Supplier | Taiyo Yuden |
| Description | FIXED IND 1.2UH 880MA 210 MOHM |
| Series | LA, L Type |
| Product Status | Obsolete |
| Shielding | Unshielded |
| Q @ Frequency | 50 @ 7.96MHz |
| Self Resonant Frequency | 144MHz |
| Inductance Test Frequency | 7.96 MHz |
| Mounting Type | Through Hole |
