Description
FIXED IND 2.7UH 310MA 767 MOHM
Specifications
Inductance
2.7 µH
Current Rating
310 mA
DC Resistance (DCR)
767mOhm Max
Dimensions
0.079" L x 0.063" W (2.00mm x 1.60mm)
Product Attributes
Manufacturer Verified
Last verified: 6/17/2026| Inductance | 2.7 µH |
| Tolerance | ±5% |
| Current Rating | 310 mA |
| DC Resistance (DCR) | 767mOhm Max |
| saturationCurrent | - |
| Operating Temperature | -40°C ~ 105°C |
| Dimensions | 0.079" L x 0.063" W (2.00mm x 1.60mm) |
| Case / Size | 0806 (2016 Metric) |
| Supplier | Taiyo Yuden |
| Description | FIXED IND 2.7UH 310MA 767 MOHM |
| Series | LB, M Type |
| productStatus | Not For New Designs |
| typeConstruction | Drum Core, Wirewound |
| coreMaterial | Ferrite |
| shielding | Unshielded |
| qFactor | 30 @ 7.96MHz |
| selfResonantFreq | 55MHz |
| ratings | - |
| testFrequency | 7.96 MHz |
| mountingType | Surface Mount |
| supplierDevicePackage | 0806 (2016 Metric) |
| heightMax | 0.071" (1.80mm) |
| features | - |
