Description
FIXED IND 1.6NH 500MA 180 MOHM
Specifications
Parameter Guide
Understand the key electrical and mechanical specifications for LCCI0201S1N6GTAR.
LCCI0201S1N6GTAR has an inductance value of 1.6 nH. This value indicates how much magnetic energy the component can store and is one of the first parameters to compare when selecting an inductor.
LCCI0201S1N6GTAR is rated for 500 mA. Current rating helps determine whether the part can carry the expected DC or RMS current without excessive heating or saturation risk.
LCCI0201S1N6GTAR lists a DC resistance of 180mOhm Max. Lower DCR usually reduces conduction loss and improves efficiency in power circuits.
LCCI0201S1N6GTAR uses a package or case of 0201 (0603 Metric). Package size affects PCB footprint, height clearance, thermal behavior, and compatibility with automated assembly.
Explore Related Datasheet Paths
Continue from LCCI0201S1N6GTAR to manufacturer, series, and broader datasheet collections.
Product Attributes
| Inductance | 1.6 nH |
| Tolerance | ±0.3nH |
| Current Rating | 500 mA |
| DC Resistance (DCR) | 180mOhm Max |
| Saturation Current | - |
| Operating Temperature | -40°C ~ 85°C |
| Dimensions | 0.024 L x 0.012 W (0.60mm x 0.30mm) |
| Case / Size | 0201 (0603 Metric) |
| Package / Case | 0201 (0603 Metric) |
| Supplier | KYOCERA AVX |
| Description | FIXED IND 1.6NH 500MA 180 MOHM |
| Series | LCCI |
| Product Status | Active |
| Type / Construction | Multilayer |
| Core Material | Ceramic |
| Shielding | Unshielded |
| Q @ Frequency | 4 @ 100MHz |
| Self Resonant Frequency | 10GHz |
| Ratings | - |
| Inductance Test Frequency | 100 MHz |
| Mounting Type | Surface Mount |
| Supplier Device Package | 0201 |
| Height - Seated (Max) | 0.013 (0.33mm) |
| Features | - |
