Description
FIXED IND 240NH 3.5A 26 MOHM SMD
Specifications
Parameter Guide
Understand the key electrical and mechanical specifications for MBMK2520HR24N.
MBMK2520HR24N has an inductance value of 240 nH. This value indicates how much magnetic energy the component can store and is one of the first parameters to compare when selecting an inductor.
MBMK2520HR24N is rated for 3.5 A. Current rating helps determine whether the part can carry the expected DC or RMS current without excessive heating or saturation risk.
MBMK2520HR24N lists a DC resistance of 26mOhm Max. Lower DCR usually reduces conduction loss and improves efficiency in power circuits.
MBMK2520HR24N uses a package or case of 1008 (2520 Metric). Package size affects PCB footprint, height clearance, thermal behavior, and compatibility with automated assembly.
Explore Related Datasheet Paths
Continue from MBMK2520HR24N to manufacturer, series, and broader datasheet collections.
Alternative Solutions
Compare possible alternatives with similar specifications. Verify every electrical and mechanical requirement before use.
Product Attributes
| Inductance | 240 nH |
| Tolerance | ±30% |
| Current Rating | 3.5 A |
| DC Resistance (DCR) | 26mOhm Max |
| Saturation Current | 4.75A |
| Operating Temperature | -40°C ~ 125°C |
| Dimensions | 0.098" L x 0.079" W (2.50mm x 2.00mm) |
| Case / Size | 1008 (2520 Metric) |
| Package / Case | 1008 (2520 Metric) |
| Supplier | Taiyo Yuden |
| Description | FIXED IND 240NH 3.5A 26 MOHM SMD |
| Series | MCOIL™, MB, H Type |
| Product Status | Active |
| Type / Construction | Drum Core, Wirewound |
| Core Material | Metal |
| Shielding | Shielded |
| Inductance Test Frequency | 1 MHz |
| Mounting Type | Surface Mount |
| Supplier Device Package | 1008 (2520 Metric) |
| Height - Seated (Max) | 0.047" (1.20mm) |
