Description
FIXED IND 68 NH 100 MA 3.2 OHM
Specifications
Parameter Guide
Understand the key electrical and mechanical specifications for MGCI0603Q68NJT-LF.
MGCI0603Q68NJT-LF has an inductance value of 68 nH. This value indicates how much magnetic energy the component can store and is one of the first parameters to compare when selecting an inductor.
MGCI0603Q68NJT-LF is rated for 100 mA. Current rating helps determine whether the part can carry the expected DC or RMS current without excessive heating or saturation risk.
MGCI0603Q68NJT-LF lists a DC resistance of 3.2Ohm Max. Lower DCR usually reduces conduction loss and improves efficiency in power circuits.
MGCI0603Q68NJT-LF uses a package or case of 0201 (0603 Metric). Package size affects PCB footprint, height clearance, thermal behavior, and compatibility with automated assembly.
Explore Related Datasheet Paths
Continue from MGCI0603Q68NJT-LF to manufacturer, series, and broader datasheet collections.
Product Attributes
| Inductance | 68 nH |
| Tolerance | ±5% |
| Current Rating | 100 mA |
| DC Resistance (DCR) | 3.2Ohm Max |
| Operating Temperature | -55°C ~ 125°C |
| Dimensions | 0.024 L x 0.012 W (0.60mm x 0.30mm) |
| Case / Size | 0201 (0603 Metric) |
| Package / Case | 0201 (0603 Metric) |
| Supplier | Microgate Technology |
| Description | FIXED IND 68 NH 100 MA 3.2 OHM |
| Series | MGCI0603Q |
| Product Status | Active |
| Type / Construction | Multilayer |
| Core Material | Ceramic |
| Shielding | Unshielded |
| Q @ Frequency | 13 @ 500MHz |
| Self Resonant Frequency | 1.2GHz |
| Inductance Test Frequency | 500 MHz |
| Mounting Type | Surface Mount |
| Supplier Device Package | 0201 |
| Height - Seated (Max) | 0.012 (0.30mm) |
