Description
FIXED IND 0.6NH 1A 70 MOHM SMD
Specifications
Parameter Guide
Understand the key electrical and mechanical specifications for MHQ0603P0N6BT000.
MHQ0603P0N6BT000 has an inductance value of 0.6 nH. This value indicates how much magnetic energy the component can store and is one of the first parameters to compare when selecting an inductor.
MHQ0603P0N6BT000 is rated for 1 A. Current rating helps determine whether the part can carry the expected DC or RMS current without excessive heating or saturation risk.
MHQ0603P0N6BT000 lists a DC resistance of 70mOhm Max. Lower DCR usually reduces conduction loss and improves efficiency in power circuits.
MHQ0603P0N6BT000 uses a package or case of 0201 (0603 Metric). Package size affects PCB footprint, height clearance, thermal behavior, and compatibility with automated assembly.
Explore Related Datasheet Paths
Continue from MHQ0603P0N6BT000 to manufacturer, series, and broader datasheet collections.
Product Attributes
| Inductance | 0.6 nH |
| Tolerance | ±0.1nH |
| Current Rating | 1 A |
| DC Resistance (DCR) | 70mOhm Max |
| Operating Temperature | -55°C ~ 125°C |
| Dimensions | 0.026" L x 0.014" W (0.65mm x 0.35mm) |
| Case / Size | 0201 (0603 Metric) |
| Package / Case | 0201 (0603 Metric) |
| Supplier | TDK |
| Description | FIXED IND 0.6NH 1A 70 MOHM SMD |
| Series | MHQ-P |
| Product Status | Active |
| Type / Construction | Multilayer |
| Core Material | Ceramic, Non-Magnetic |
| Shielding | Unshielded |
| Self Resonant Frequency | 10GHz |
| Inductance Test Frequency | 500 MHz |
| Mounting Type | Surface Mount |
| Supplier Device Package | 0201 (0603 Metric) |
| Height - Seated (Max) | 0.016" (0.40mm) |
