Description
FIXED IND 140NH 450MA 450 MOHM
Specifications
Parameter Guide
Understand the key electrical and mechanical specifications for MLJ1005WR14JT000.
MLJ1005WR14JT000 has an inductance value of 140 nH. This value indicates how much magnetic energy the component can store and is one of the first parameters to compare when selecting an inductor.
MLJ1005WR14JT000 is rated for 450 mA. Current rating helps determine whether the part can carry the expected DC or RMS current without excessive heating or saturation risk.
MLJ1005WR14JT000 lists a DC resistance of 450mOhm Max. Lower DCR usually reduces conduction loss and improves efficiency in power circuits.
MLJ1005WR14JT000 uses a package or case of 0402 (1005 Metric). Package size affects PCB footprint, height clearance, thermal behavior, and compatibility with automated assembly.
Explore Related Datasheet Paths
Continue from MLJ1005WR14JT000 to manufacturer, series, and broader datasheet collections.
Alternative Solutions
Compare possible alternatives with similar specifications. Verify every electrical and mechanical requirement before use.
Product Attributes
| Inductance | 140 nH |
| Tolerance | ±5% |
| Current Rating | 450 mA |
| DC Resistance (DCR) | 450mOhm Max |
| Saturation Current | 380mA |
| Operating Temperature | -55°C ~ 125°C |
| Dimensions | 0.039" L x 0.020" W (1.00mm x 0.50mm) |
| Case / Size | 0402 (1005 Metric) |
| Package / Case | 0402 (1005 Metric) |
| Supplier | TDK |
| Description | FIXED IND 140NH 450MA 450 MOHM |
| Series | MLJ |
| Product Status | Active |
| Type / Construction | Multilayer |
| Core Material | Ferrite |
| Shielding | Shielded |
| Q @ Frequency | 15 @ 25MHz |
| Self Resonant Frequency | 400MHz |
| Inductance Test Frequency | 25 MHz |
| Mounting Type | Surface Mount |
| Supplier Device Package | 0402 |
| Height - Seated (Max) | 0.022" (0.55mm) |
