Description
FIXED IND 39NH 540MA 240 MOHM
Specifications
Parameter Guide
Understand the key electrical and mechanical specifications for MLRF0603-039J.
MLRF0603-039J has an inductance value of 39 nH. This value indicates how much magnetic energy the component can store and is one of the first parameters to compare when selecting an inductor.
MLRF0603-039J is rated for 540 mA. Current rating helps determine whether the part can carry the expected DC or RMS current without excessive heating or saturation risk.
MLRF0603-039J lists a DC resistance of 240mOhm Max. Lower DCR usually reduces conduction loss and improves efficiency in power circuits.
MLRF0603-039J uses a package or case of 0603 (1608 Metric). Package size affects PCB footprint, height clearance, thermal behavior, and compatibility with automated assembly.
Explore Related Datasheet Paths
Continue from MLRF0603-039J to manufacturer, series, and broader datasheet collections.
Product Attributes
| Inductance | 39 nH |
| Tolerance | ±5% |
| Current Rating | 540 mA |
| DC Resistance (DCR) | 240mOhm Max |
| Operating Temperature | -55°C ~ 125°C |
| Dimensions | 0.071" L x 0.047" W (1.80mm x 1.20mm) |
| Case / Size | 0603 (1608 Metric) |
| Package / Case | 0603 (1608 Metric) |
| Supplier | Gowanda |
| Description | FIXED IND 39NH 540MA 240 MOHM |
| Series | MLRF0603 |
| Product Status | Active |
| Core Material | Ceramic |
| Shielding | Unshielded |
| Q @ Frequency | 40 @ 250MHz |
| Self Resonant Frequency | 2.2GHz |
| Inductance Test Frequency | 250 MHz |
| Mounting Type | Surface Mount |
| Supplier Device Package | 603 |
| Height - Seated (Max) | 0.040" (1.02mm) |
