Description
FIXED IND 27NH 670MA 250 MOHM
Specifications
Parameter Guide
Understand the key electrical and mechanical specifications for MLRF0805-027G.
MLRF0805-027G has an inductance value of 27 nH. This value indicates how much magnetic energy the component can store and is one of the first parameters to compare when selecting an inductor.
MLRF0805-027G is rated for 670 mA. Current rating helps determine whether the part can carry the expected DC or RMS current without excessive heating or saturation risk.
MLRF0805-027G lists a DC resistance of 250mOhm Max. Lower DCR usually reduces conduction loss and improves efficiency in power circuits.
MLRF0805-027G uses a package or case of 0805 (2012 Metric). Package size affects PCB footprint, height clearance, thermal behavior, and compatibility with automated assembly.
Explore Related Datasheet Paths
Continue from MLRF0805-027G to manufacturer, series, and broader datasheet collections.
Product Attributes
| Inductance | 27 nH |
| Tolerance | ±2% |
| Current Rating | 670 mA |
| DC Resistance (DCR) | 250mOhm Max |
| Saturation Current | - |
| Operating Temperature | -55°C ~ 125°C |
| Dimensions | 0.095" L x 0.070" W (2.41mm x 1.78mm) |
| Case / Size | 0805 (2012 Metric) |
| Package / Case | 0805 (2012 Metric) |
| Supplier | Gowanda |
| Description | FIXED IND 27NH 670MA 250 MOHM |
| Series | MLRF0805 |
| Product Status | Active |
| Type / Construction | - |
| Core Material | Ceramic |
| Shielding | Unshielded |
| Q @ Frequency | 55 @ 500MHz |
| Self Resonant Frequency | 2.3GHz |
| Ratings | - |
| Inductance Test Frequency | 250 MHz |
| Mounting Type | Surface Mount |
| Supplier Device Package | 805 |
| Height - Seated (Max) | 0.060" (1.52mm) |
| Features | - |
