Description
FIXED IND 680NH 450MA 230 MOHM
Specifications
Parameter Guide
Understand the key electrical and mechanical specifications for MLZ1005MR68WTD25.
MLZ1005MR68WTD25 has an inductance value of 680 nH. This value indicates how much magnetic energy the component can store and is one of the first parameters to compare when selecting an inductor.
MLZ1005MR68WTD25 is rated for 450 mA. Current rating helps determine whether the part can carry the expected DC or RMS current without excessive heating or saturation risk.
MLZ1005MR68WTD25 lists a DC resistance of 230mOhm. Lower DCR usually reduces conduction loss and improves efficiency in power circuits.
MLZ1005MR68WTD25 uses a package or case of 0402 (1005 Metric). Package size affects PCB footprint, height clearance, thermal behavior, and compatibility with automated assembly.
Explore Related Datasheet Paths
Continue from MLZ1005MR68WTD25 to manufacturer, series, and broader datasheet collections.
Product Attributes
| Inductance | 680 nH |
| Tolerance | ±20% |
| Current Rating | 450 mA |
| DC Resistance (DCR) | 230mOhm |
| Saturation Current | 110mA |
| Operating Temperature | -55°C ~ 125°C |
| Dimensions | 0.039" L x 0.020" W (1.00mm x 0.50mm) |
| Case / Size | 0402 (1005 Metric) |
| Package / Case | 0402 (1005 Metric) |
| Supplier | TDK |
| Description | FIXED IND 680NH 450MA 230 MOHM |
| Series | MLZ |
| Product Status | Active |
| Type / Construction | Multilayer |
| Core Material | Ferrite |
| Shielding | Shielded |
| Inductance Test Frequency | 2 MHz |
| Mounting Type | Surface Mount |
| Supplier Device Package | 0402 |
| Height - Seated (Max) | 0.022" (0.55mm) |
